Aluminium 7075 Flat Bars
When peak strength, rugged performance and lightweight design are vital, Aluminium 7075 Flat Bars are the first choice. Known for being one of the strongest wrought aluminium alloys available, 7075 excels in demanding applications where failure is not an option. As a prominent Aluminium 7075 Flat Bars Manufacturer, we supply premium quality 7075 Aluminium Flat Bars with tight tolerances, superior mechanical characteristics, and consistent finishes. Whether for aerospace, automotive, structural, or military use, our 7075 Flat Bars deliver unmatched performance.
Related
Products
What Are 7075 Aluminium Flat Bars?
7075 Aluminium Flat Bars are flat bars made from aluminium alloy 7075, a high-zinc, high strength alloy in the 7000 series. These flat bars are fabricated by extrusion or cold finishing to produce rectangular cross-sections with precise dimensions. As Aluminium 7075 Flat Bars, they offer high strength, good fatigue resistance, and are often used in high-stress environments. Their mechanical properties are superior to many steels on strength-to-weight ratio, making 7075 Flat Bars ideal where weight savings are as important as strength.
Â
Tempers & Their Effects
The performance of Aluminium 7075 Flat Bars depends greatly on the temper (heat treatment & work-hardening). Common tempers include:
- T6 / T651 – Solution heat treated, artificially aged, sometimes stretched. Exhibits very high tensile strength and good yield strength.
- T7351 – Treated to improve stress-corrosion cracking resistance, while maintaining high strength. Good for critical structural applications.
- Other variants (-T6511, T3511, etc.) that may provide slight differences in fatigue, machinability or form stability.Â
Advantages of Aluminium 7075 Flat Bars
- Exceptional Strength-to-Weight Ratio — These bars deliver strength comparable to mild steel while being significantly lighter.
Â
- High Fatigue Resistance — Especially in tempers engineered for improved stress-corrosion resistance, 7075 Flat Bars perform well in repetitive load conditions.
Â
- Great Machinability — In many tempers, 7075 Aluminium Flat Bars can be machined to tight tolerances and fine finishes.
Â
- Dimensional Stability — Because of stable tempers like T651 & T7351, shape retention under stress or thermal cycles is reliable.
Â
- Premium Applications Compatibility — Used in aerospace, defense, high performance automotive, precision machinery etc. where quality and performance cannot be compromised.
Â
Limitations & Considerations
- Weldability: Aluminium 7075 is generally not readily weldable in many of its strong tempers; welding may compromise the strength and stress-corrosion resistance.
Â
- Cost: As a high performance alloy, 7075 Aluminium Flat Bars are more expensive than more common alloys (6000 series etc.).
Â
- Corrosion Sensitivity: Although tempers like T7351 improve stress corrosion resistance, in certain environments (marine, high humidity, corrosive chemicals), protective coatings or finishes may be required.
Â
- Formability: Less ductile than softer alloys; bending/forming must be done with care, particularly in hardened tempers.
Â
- Weldability: Aluminium 7075 is generally not readily weldable in many of its strong tempers; welding may compromise the strength and stress-corrosion resistance.
Applications of 7075 Flat Bars
Thanks to their strength and other favourable properties, 7075 Flat Bars are used in many high-demand sectors:
- Aerospace & Defense: Structural parts, aircraft fittings, fuselage components, wing spars.
- Automotive & Motorsports: High performance or racing parts – connectors, shafts, mounts where weight reduction and strength are critical.
- Sports Equipment: Parts of bicycle frames, gears, components for climbing gear etc. where fatigue resistance matters.
- Tooling & Molds: Some tooling where high strength and dimensional stability are needed.
- Fatigue & Load Critical Industrial Machinery: Shafts, gears, load bearing components in machines exposed to cyclical stress.
Â
Standards & Sizes
Standards / Specifications
To ensure reliability and traceability, Aluminium 7075 Flat Bars are often supplied conforming to international & industrial standards:
- ASTM B221 for bars & extruded shapes
- AMS / QQ standards – e.g. AMS-QQ-A-225/9, AMS-4122/4123/4124 for rods, bars in different shapes & tempers.
Size & Form Availability
7075 Flat Bars are available in a wide variety of widths, thicknesses, and lengths. Some common offerings include:
- Flat bars in cold finished and extruded forms.
- Thickness & width dimensions ranging from small sizes (fractions of an inch) to large industrial sizes. Custom cuts are possible.
- Standard tempers in flat bar form: T6, T651, T7351 etc.
Why Choose Us: Your Trusted Aluminium 7075 Flat Bars Manufacturer
When performance is non-negotiable, selecting the right Aluminium 7075 Flat Bars Manufacturer is critical. Here’s what sets premium manufacturers apart:
- Material Traceability & Certification — We provide chemical and mechanical test reports confirming compliance with international standards (ASTM, AMS etc.).
Â
- Consistent Quality & Finish — Precision in surface finish, flatness, tolerances. Excellent cold finish when required.
Â
- Wide Range of Tempers & Sizes — Capability to offer 7075 Aluminium Flat Bars in the tempers that suit your use case (T6, T7351, etc.), and cut to your required dimensions.
Â
- Experienced Machining & Processing — Knowledge of handling 7075’s limitations: machining strategies, avoiding weld zones, surface treatments if needed.
Â
- Reliable Supply & Logistics — Timely delivery, good packaging, accessible technical support.
Â
We as an Aluminium 7075 Flat Bars Manufacturer pride ourselves on offering all these. Whether you need a prototype batch or large scale supply, our capacity and processes ensure the product you receive matches spec.
How to Specify & Order Aluminium 7075 Flat Bars
Here are some guidelines to help you order the right 7075 Aluminium Flat Bars for your application:
- Define Temper: Decide whether T6, T651, T7351 or other temper is required based on strength, fatigue, and corrosion requirement.
Â
- Specify Dimensions: Thickness, width, length; tolerances on flatness, edge finish.
Â
- Surface Finish & Treatment: If the bar will be exposed or needs superior finish, require mill finish, cold finish, or special surface treatment/coating.
Â
- Mechanical Properties: Full yield, tensile, elongation, hardness expectations.
Â
- Standards Compliance: Ensure alloy & temper conform to recognized standards (ASTM, AMS, etc.).
Â
- Quantity & Lead Time: Flat bars may have lead times in large sizes or particular tempers.
Â
- Define Temper: Decide whether T6, T651, T7351 or other temper is required based on strength, fatigue, and corrosion requirement.
Conclusion
Aluminium 7075 Flat Bars are premium products built for demanding tasks. Their exceptional strength, fatigue resistance, stable dimensions, and high performance make them a go-to for aerospace, defense, motorsports, tooling, and other high-stress applications. When sourced from a top-quality Aluminium 7075 Flat Bars Manufacturer, you gain assurance in material quality, stand-out mechanical properties, and suitability for mission-critical use.
If your project demands the best—strength, precision, durability—choose 7075 Aluminium Flat Bars. Contact us today to get quotes, certifications, custom sizes and finishes, and experience the difference in high-performance material supply from an experienced Aluminium 7075 Flat Bars Manufacturer.
